MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • ISELI
  • Model:
  • 022220 - ISELI AS 2
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

from: 15 mm/dent.
up to: 100 mm/dent.
Tooth height: 40 mm.
Circular saw boring diameter: 22 - 210 mm.
Clamping angle: 0 - 30 °.
Grinding angle: 0 - 15 °.
Diameter of grinding wheel: 200 / 250 mm.
Max. grinding wheel width: 16 mm.
Drilling cap. of grind.wheel: 25 mm.
Feeds steps:: 4.
Coolant pressure: 6 bar.
Voltage 50 Hz 3x: 380 Volt.
grinding motor: 1 kW.
Required power: kW.
Machine's weight about: 500 kg.
Length: 1500 mm.
Width: 1000 mm.
Height: 1800 mm.
