Number of axis total 4
Drill capacity in steel 28 mm
Threat cutting in steel M 24
Milling capacity 100 cm3/min
Spindle stroke 160 mm
Spindle speeds :stepless
from 50 rpm
up to 7100 rpm
Table length 880 mm...
FICEP
10033
NOMINAL FORCE kN 10.000
Force kN 20.000
Screw diameter mm 315
Max usable energy Kgm 12.000
Slide stroke mm 500
Theoretical strokes per minute N° 26
Vertical clearance height mm 800
Horizontal clearance height mm 750
Table dimensions leng...
With the use of seal kits leaks from the front of back of the cylinder can be stopped. The replacementf of the seals can either be done in house or can be sent to 1st Machine Tool Accessories for replacement by one of our technicians.
