MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Favretto
  • Model:
  • 022500 - FAVRETTO MC 100
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Table length: 1200 mm.
Table width: 500 mm.
Longitudinal travel (X-axis): 1120 mm.
Cross travel (z-axis): 635 mm.
vertical travel (Y-axis): 690 mm.
Table load max.: 1000 kg.
Grinding length: 1000 mm.
Grinding width: 700 mm.
Grinding height over table: 650 mm.
Diameter: 406 mm.
Width: 500 mm.
Bore: 152 mm.
Grinding wheel speeds fix: 1400 t/min.
from: m/min.
up to: 2 m/min.
Voltage 50 Hz 3x: 400 Volt.
Grinding spindle motor: 11 kW.
Total power required: 31 kW.
Machine's weight about: 7800 kg.
Length: 1000 mm.
Height: 2680 mm.
