MERLI CLOVIS
07421
MOD. CLOVIS 28
Lenght mm 2000
Height of center mm 410
Turnng Diameter on bed mm 600
Bar capaciry mm 105
Bed Widht mm 450
Diamter qill mm 100
With:
Self center Pinto diam 350 mm
DG 3+3 foro 120
Steady rest diam mm 400
USED MACHINE
CAMS
08800
Adjustable tool stroke from 0 to 200 mm
Distance between column and tool holder mm 350
Distance between rotary table and head 360 mm
Vertical movement of the ram 370 mm
Rotary table dimensions (manual A axis) diam. 320 mm
Longitudinal stro...
