MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • Model:
  • 022599 - FMB Turbo Turbo 3-26
  • Condition:
  • 1
  • YOM:
  • NA
  • Control:
  • NA
  • Price:
  • POA
  • Country:

DESCRIPTION

Bar diameter round up: 3 mm.
up to: 26 mm.
Length of bars max.: 3200 mm.
Outstanding length min.: 450 mm.
Feed range: 0 - 400 mm/s.
Max. Feed force: 550 N.
Voltage 50 Hz 3x: 400 Volt.
Power: 2 kW.
Compressed air from: 6 bar.
Machine's weight about: 750 kg.
Length: 4700 mm.
Width: 700 mm.
Height: 1500 mm.
+ request more information
