SACHMAN
09686
TABLE mm 1350 X 550
STROKE LONGITUDINAL mm 1200
STROKE TRASVERSAL mm 600
STROKE VERTICAL mm 650
STROKE QUILL mm 160
HEAD ROTATION +- 45 gradi
SPINDLE ROTAZION 40-2000 RPM
DIGITAL READOUT OPTICAL 2 AXIS
USED MACHINE
Scherer Feinbau GmbH model WDZ250 CNC vertical turning lathe (to include all product specific work piece holders and tooling, etc.)
Serial No. 80056, YoM 2012. include also Schnalthmann Maschinenbau GmbH chain conveyor charging and discharging sys...
ANNO: 2004
S/N: T-0872
C.N. SODICK LQ1W
Tavola: 790 x 500 mm
CORSE:
Altezza massima del pezzo: 290 mm x 270 mm a immersione
Peso massimo del pezzo: 800 Kg x 680Kg a immersione
Distanza pavimento – superficie tavola: 1005 mm
Angolo cono: 20° / 80 m...
Fully machinable aluminium jaws for use on either 1540 Qwik-Loks or 1540 Multi-Loks.
The Dual Station Machinable Jaw Sets clamp with an equal and opposing inward force,
Thus eliminating the potential for jaw lift. The safe low profile jaw inter...
