JOBS
09418
CNC Heidenhain TNC530 HSCI with handwheel HR 410
X-axis stroke mm 4000
Y-axis stroke mm 2500
Z axis stroke mm 1500
X,Y,Z axis max speed m/min 25
X,Y,Z axis max acceleration m/sec2 0.75
Max thrust X,Y,Z axes N 10000
X axis transmission rack...
OMG ZANOLETTI
09327
Center height mm 250
Turning diameter on the bed mm 500
Rotary diameter on the gap mm 680
Turning diameter on the transversal carriage mm 300
Bed width 330 mm
Distance between centers mm 1500
Bar passaging mm 90
Min/max spindle sp...
MAUT
09200
CNC HEIDENHAIN TNC 530
AXIS STROKES:
Longitudinal stroke X axis 7000 mm
Vertical travel Z axis 1500 mm
Cross travel Y axis 3600 mm
WORK PLAN:
Dimensions mm 9000x2500x300
T-slots n.10, mm 22 H7
Distance between T-slots 250 mm
FEEDRATES:
Wor...
