TECH
08919
MANUAL
Tool travel 0-315 mm
Strokes per minute 14 - 60
Ram adjustment 235 mm
Swivel angle of head ±45°
Head to table distance 510 mm
Tool to column distance 460 mm
Diameter of rotating table 450 mm
Diameter of central hole of rotating ta...
PADOVANI
08827
DIMENSIONS:
Height of centers mm 200
Distance between centers mm 1500
Bed width mm 290
Max turning diameter on the bed mm 400
Max turning diameter on the carriage mm 245
GAP:
Width mm 240
Max swing diameter mm 600
SPINDLE:
Front bearin...
CORREA
09184
CNC HEIDENHAIN
Axis X stroke mm 2000
Axis Y stroke mm 800
Axis Z stroke mm 800
Table dimensions mm 2000x700
Max spindle speed rpm 3000
Spindle taper ISO 50
Spindle motor power kW 17
Approx. machine weight Kg 9000
EQUIPPED WITH:
-Bi-rotat...
NOVAR
06619
CNC HEIDENHAIN TNC 135
-Woring plane mm 1500x360
-Longitudinal stroke mm 1200
-Cross stroke mm 420
-Verticale stroke mm 620
-Spindle taper ISO 50
USED MACHINE
