MACHINE INFORMATION AND SPECIFICATION

Category:
Miscellaneous

Manufacturer:
Hauser

Model:
020664 - HAUSER S 40 CNC

Condition:
1

YOM:
NA

Control:
NA

Price:
POA

Seller:
Muller Machines SA

Country:

DESCRIPTION

Table length: 770 mm.
Table width: 630 mm.
Table load max.: 500 kg.
Longitudinal travel (X-axis): 650 mm.
Transversal travel (y-axis): 450 mm.
Verticla travel (W-axis): 500 mm.
Max. grinding diameter: 230 mm.
with display-plate: 360 mm.
Stroke of spindle-nose: 125 mm.
up to: 80000 t/min.
up to grinding depth: 44 mm.
from Vmin.: 1 mm/min.
up to Vmax.: 12000 mm/min.
Stroke frequency Z: 4 Hz.
Radiale fine feed U-axis up to: 6 mm.
from: 4500 t/min.
With air-turbine max.: 160000 t/min.
Voltage 50 Hz 3x: 380 Volt.
Machine's weight about: 5600 kg.
Length: 2650 mm.
Width: 2000 mm.
Height: 3150 mm.

+ request more information
