MACHINE INFORMATION AND SPECIFICATION

  • Manufacturer:
  • LISSMAC
  • Model:
  • Lissmac - SBM-XL 1000 G2S2
  • Condition:
  • Used
  • YOM:
  • 2012
  • Control:
  • NA
  • Price:
  • POA
  • Country:
  • Germany Germany

DESCRIPTION

  • max. working width: 1000 mm
  • workable material thickness: 0,5 - 50 mm
  • Working hours machine: 600 h
  • Total power: 82 A
  • Total current consumption: 44,5 kW
  • Insulation class: IP 42
  • Infinitely variable feed speed: 0-4 m / min
  • Adjustment of material thickness: elektrisch
  • Adjustment of tools: elektrisch
  • Length: 3100 mm
  • Width: 2100 mm
  • Height: 2000 mm
  • Machine weight: 3800 kg
  • Standard configuration:
  • Deburring and edge rounding of parts up to 120 mm material thickness Processing both sides of the parts simultaneously eliminates the need of turning heavy parts and processing them for a second time Simultaneous deburring and edge rounding on interior and exterior contours Dry operation Simple, intuitive operation The processing units can be individually adjusted or turned on and off electrically. Maximum productivity while maintaining machining quality The cross-machining principle guarantees optimum tool utilisation over the entire working width. Faster and simpler tool change within just a few minutes. Modular and compact in modern machine design - smaller footprint Improved work environment - Reduction of dust, dirt and noise Optionally available: Conveyor Technology; Handling Systems, Automation; Custom Solutions For repeated customer requirements, processing parameters can be called up quickly and easily through predefined programs. Up to 60 % work time savings compared to one-side processing grinding machines
  • Extended machine accessories:
  • dust extractor
  • Description:
  • LISSMAC systems for metal processing set benchmarks in innovative sheet metal processing through highly-effective, two-sided deburring and edge rounding on plasma and thermal cut workpieces using only one work process. Unlike grinding machines, SBM-XL G2S2s win over customers with more efficient processing work savings of up to 60%.
