MEP
07348
CUTTING CAPACITY:
-0 degrees Round mm 210, Square mm 200, Rectangle mm 270x200
-45 degrees Sx Round mm 180, Square mm 180, Rectangle mm 180x190
-60 degrees Sx Round mm 100, Square mm 90, Rectangle mm 120x90
BLADE:
-Blade dimensions mm 2750x...
FAMUP
09662
Selca 3045 CNC
TRAVELS:
X axis 1200 mm
Y axis 600 mm
Z axis 600 mm
TABLE:
Table size 1380x620 mm
T-slots 5
T-slots widht mm 18
T-slots distance mm 125
Max table load 800 kg
SPINDLE:
Spindle taper DIN69871 ISO 40
Spindle speed 50-10.000 rp...
08116
PLATINUM ARM
2,4 mt and 6 axis
Repeatability test
EQUIPED WITH:
- Measuring arm
- Bluetooth
- Probes (1x3 mm) (1x6 mm)
- Plate for assembly
- Transport case
- Magnetic base
- Software CAM 2Q
USED MACHINE
MIKRON
06708
CNC HAAS
Table dimensions 1625x710 mm
Max load capacity 1800 Kg
Axis X 1620 mm
Axis Y 810 mm
Axis Z 760 mm
Rapid feed axis X 13 m/min
Rapid feed axis Y 15 m/min
Rapid feed axis Z 15 m/min
Spindle speed 7500 rpm
Spindle motor power 11 Kw
...
