KONDIA
New02734
NUMERIC CONTROL HEIDENHAIN TNC 150
AXIS X MM.600
AXIS Y MM.350
QUILL VERTICAL AXIS Z MM.125
MAX WORKPIECE WEIGHT 225 KG.
TABLE SIZE MM. 700X300
T SLOTS (DISTANCE BETWEEN T SLOTS) 3 (75 MM.)
T SLOTS WIDTH MM.16
2 SPINDLE RANGE MOTOR 2/...
MEXIM
08259
Table dimensions mm 1600x360
Axis X stroke mm 1100
Axis Y stroke mm 300
Axis Z stroke mm 420
Spindle speed n.12 / rpm 56-1800
Spindle motor power kW 7,5
Total installed power kW 15
EQUIPPED WITH:
-Universal head HURON ISO 50
-DRO 3 axis
...
